KNR Residences

BASEMENT / FOUNDATION

• Basement will be brickwork in C.M. 1:6(1 cement: 6 sand) mix using good quality of Chamber Bricks, 230 mm thick brick wall to height 2.5 ft. from existing ground level.
• Basement filling will be excavated earth and locally available pit sand.
• Providing and laying plain cement concrete ratio 1:4:8 using hard granite stone jelly of size 40mm including, consolidation, finishing as directed and curing, etc.
• The ceiling height will be as per the CMDA approvals 10 feet [slab to slab]
• Pre-construction anti termite/pest control treatment as per IS6313 - 1981.

STRUCTURE

• Earthquake resistant structural design
• R.C.C. Columns / Brick Walls with Isolated Footings or Pile foundations / plinth beams to connect.

R.C.C. WORKS

• Providing and laying cast in situ reinforced cement concrete. All RCC works will be M20/M25 grade mix by approved brands and using certified TMT bars. Confirming to the relevant IS code.
• Cement: Coramandel/Birla/Zuari or Equivalent
• Steel: ARS, Suryadev (Or) Equivalent.

BRICKWORK

PLASTERING

• Prepare surface and plaster to Ceilings,Beams, Columns, Sunshades Plastering in cement mortar 1:3 mix.
• Inner Walls: Plastering the walls with 15mm Thickness using C.M 1:4 mix with smooth sponge finishing.
• Outside Walls: Plastering the walls 20 mm Thickness using C.M 1:5 mix finishing.

CARPENTRY WORKS

• Main doors: First quality Teak WoodFrames with customized laminated doors. All main door locks will be of Godrej or YALE make only.
• Other Doors: First quality solid wood frame with approved panel doors or flush shutter Doors.
• French Doors as per the architect's design will be provided with UPVC frames and sliding shutters with 4mm glass.
• Windows: UPVC Sliding Windows with M.S grills.
• UPVC Bathroom Ventilators with louvers.

FLOORING

• 2' x 2' Premium quality vitrified Tiles byKajaria/Somany/RAK or its equivalent. Along with 4” skirting.
• Pointing with pigmented non shrinking tile Grout andoxalic acid wash will be done as per the approved standards.
• Granite floor: For Staircase and Landing Areas only.
• Pattern/Color: Sadhalli Grey or Steel Grey

WEATHERING COURSE

• Will be done using Heat Resistant Pressed clay tiles laid over Brick Jelly and Lime Concrete.
• Waterproofing treatment for the roof will be done using approved brand and manufacturer.

KITCHEN

• Kitchen counter top will be polished Black granite slabs with a stainless-steel sink.
• Make: Carysil or Frankie

TOILETS

• Non slip matt finished Ceramic tiles for the flooring and walls finished with glazed tiles 12”x 12”
• Waterproofing treatment will be done for all the sunken areas using approved brand and manufacturer.

ELECTRICAL WORKS

SANITARY WORKS

PAINTING WORKS

• Main Teak door finished with varnish and Other Doors with two coats of enamel paint over one coat of primer.
• Brands: Asian Paints
• Inner Walls Finished with two coats of Emulsion over two coats of Birla wall putty.
• Outer wall Finished with two coats of Emulsion over one coat primer.

GRILL WORK

• M.S. grills for all Windows. [10mm size]
• M.S or Stainless Steel for Staircase handrail.[As per the Architects Design]

LIFT

6 persons Johnson automatic lift with ARD facility will be provided.

GENERATOR

• 24hr power back for the entire building including the LIFT and Sump Motors. Only AC's will not be connected.
• Make: Kirloskar/Cummins/Ashok Leyland or Equivalent.

LANDSCAPING

As recommended by the Architects design.

SECURITY SYSTEMS

24-hour outdoor security cameras with 60 days of back-up recording

UG SUMP

• One 13000 ltrs capacity UG sump will be constructed as per the design and location given by the structural engineer.
• Multiple Rainwater harvesting pits will be provided.
