Elizabeth Residence

BASEMENT / FOUNDATION

• Basement will be brickwork in C.M. 1:5(1 cement: 5 sand) mix using good quality of Chamber Bricks, 230 mm thick brick wall to height 2.5 ft. from existing ground level.
• Basement filling will be excavated earth and locally available pit sand.
• Providing and laying plain cement concrete ratio 1:4:8 using hard granite stone jelly of size 40mm including, consolidation, finishing as directed and curing, etc.
• The ceiling height will be as per the CMDA approvals 10 feet [slab to slab]
• Pre-construction anti termite/pest control treatment as per IS6313 - 1981.

STRUCTURE

• Earthquake resistant structural design
• R.C.C. Columns / Brick Walls with Isolated Footings or Pile foundations / plinth beams to connect.

R.C.C. WORKS

• Providing and laying cast in situ reinforced cement concrete. All RCC works will be M20/M25 grade mix by approved brands and using certified TMT bars of 550D. Confirming to the relevant IS code.
• Cement: Coramandel/Birla/Zuari or Equivalent
• Steel: ARS, Suryadev (Or) Equivalent.
• Sand: M.Sand.

BRICKWORK

PLASTERING

• Prepare surface and plaster to Ceilings,Beams, Columns, Sunshades Plastering in cement mortar 1:3 mix.
• Inner Walls: Plastering the walls with 15mm Thickness using C.M 1:4 mix with finishing.
• Outside Walls: Plastering the walls 20 mm Thickness using C.M 1:5 mix finishing.
• Ceiling - Plastering with CM 1:4 or Plain GYPSUM false ceiling.

CARPENTRY WORKS

• Main doors: First quality Teak WoodFrames. All main door locks will be of Godrej or YALE make only.
• Other Doors: First quality solid wood frame with approved panel doors or flush shutter Doors.
• French Doors as per the architect's design will be provided with UPVC frames and sliding shutters with 4mm glass.
• Windows: White - UPVC Sliding Windows with M.S grills.
• UPVC Bathroom Ventilators with louvers.

FLOORING

• 2' x 2' Premium quality vitrified Tiles byKajaria/Somany/RAK or its equivalent. Along with 4” skirting for bedrooms 60/ sq.ft.
• Living & Dining ITALIAN MARBLE /Sukrabeige/ Base price : RS.200/sq.ft
• Pointing with pigmented non shrinking tile Grout andoxalic acid wash will be done as per the approved standards.
• Granite floor: For Staircase and Landing Areas only.
• Pattern/Color: Sadhalli Grey or Steel Grey

WEATHERING COURSE

• Will be done using Heat Resistant Pressed clay tiles laid over Brick Jelly and Lime Concrete.
• Waterproofing treatment for the roof will be done using approved brand and manufacturer.

KITCHEN

• Kitchen counter top will be polished Black granite slabs with a stainless-steel sink.
• Make: Carysil or Frankie

TOILETS

• Matt finished Ceramic tiles for the flooring and walls finished with glazed tiles upto ceiling. At the rate of rs 60/sq.ft.
• Waterproofing treatment will be done for all the sunken areas using approved brand and manufacturer.

ELECTRICAL WORKS

SANITARY WORKS

PAINTING WORKS

• Main Teak door finished with varnish and Other Doors with two coats of enamel paint over one coat of primer.
• Brands: Asian Paints
• Inner Walls Finished with two coats of Emulsion over two coats of Birla wall putty.
• Outer wall Finished with two coats of Emulsion over one coat primer.

GRILL WORK

• M.S. grills for all Windows. [10mm size]
• M.S or Stainless Steel for Staircase handrail.[As per the Architects Design]

LIFT

6 persons Johnson automatic lift with ARD facility will be provided.

GENERATOR

• 24hr power back for the entire building including the LIFT and Sump Motors. Only AC's will not be connected.
• Make: Kirloskar/Cummins/Ashok Leyland or Equivalent.

LANDSCAPING

As recommended by the Architects design.

SECURITY SYSTEMS

24-hour outdoor security cameras with 60 days of back-up recording

UG SUMP

• One 15000 ltrs capacity UG sump will be constructed as per the design and location given by the structural engineer.
• Multiple Rainwater harvesting pits will be provided.

SECURITY SYSTEMS

Concrete Overhead tank will have 8000 litres storing capacity with the automatic motor provision. Partition wall for metro water and bore water separately will be provided.
